Product Overview

Product Image

Core Parameters Summary

AC Input Range90 - 264V (Global)
Charging MethodCC / CV / Trickle (3-Stage)
Cooling SystemPassive Fanless Integration
Power Efficiency≥ 90% at full load
No-Load Power< 1.8W
Enclosure MaterialV0 Flame-Resistant PC

Core Advantages

Built to exceed consumer standards with commercial-grade engineering.

Fast Charging

High-efficiency power conversion algorithms significantly reduce charging time while maintaining cell integrity and minimizing heat generation.

Intelligent Protection

Built-in micro-controller constantly monitors voltage, current, and temperature in real-time to ensure absolute operational safety.

Wide Compatibility

Broad AC input range (90-264V) accommodates global power grid standards seamlessly without requiring manual voltage switching.

Industrial Grade

Robust fanless passive cooling architecture and rugged V0 flame-resistant casing designed specifically for harsh environments.

Energy Efficient

Exceeds 92% efficiency at full load and consumes less than 1.8W in standby, minimizing wasted power and reducing operational costs.

8-Level Safety Protection

Comprehensive, redundant electronic safeguards ensure risk-free charging environments.

Active Monitoring Active

Overcurrent Protection

Instantly limits current output if the draw exceeds safe operational parameters, preventing wire overheating.

Short Circuit Protection

Detects output shorts in microseconds and halts power delivery until the fault is physically cleared.

Overvoltage Protection

Clamps the output voltage to prevent spikes from damaging the sensitive BMS inside the lithium pack.

Reverse Polarity

Blocks current flow completely if the charger is connected incorrectly, eliminating the risk of spark or fire.

Overtemperature

Monitors internal thermals; reduces output or shuts down entirely if ambient heat pushes the unit past safe limits.

12-Hour Auto-Shutoff

Hard-coded timeout prevents continuous indefinite charging if a damaged battery fails to reach terminal voltage.

Full-Charge Shutoff

Cuts power mechanically when the trickle phase confirms the cells are at 100% capacity.

Recharge Wake-Up

Automatically re-engages charging if the battery drops below a threshold voltage while still plugged in.

Technical Specifications Comparison

Select the right voltage and amperage for your battery architecture.

36V and 48V Series Configurations

Note: 'R42' models output 42.0V for 36V nominal packs (10S). '546' models output 54.6V for 48V nominal packs (13S).

Model No.	Output Voltage / Current	Input Frequency	Input Voltage Range	Efficiency	Communication	Certifications
R4202	42.0V / 2A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
R4203	42.0V / 3A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
R4204	42.0V / 4A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
R4206	42.0V / 6A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
54602	54.6V / 2A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
54603	54.6V / 3A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
54604	54.6V / 4A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC
54605	54.6V / 5A	50/60Hz	90-264V AC	≥90%	CAN, UART, NTC, RS485	CE, FCC, UL, RoHS, PSE, KC

Ready to Source This Charger?

Contact our B2B team for bulk pricing, custom configurations, and OEM partnership opportunities.

Request B2B Quote

Application Scenarios

Versatile performance across different operating environments.

Daily Commuter Vehicles

Reliable charging solutions for daily commute electric bikes, enabling seamless home and office charging experiences.

Shared Mobility Fleets

Efficient fleet charging infrastructure for shared mobility services, supporting multiple vehicles with fast and reliable charging.

Micro-Mobility Hardware

Versatile charging compatibility for various micro-mobility devices including e-scooters, folding bikes, and compact electric vehicles.

DIY Retrofit Kits

Complete retrofit solutions for custom electric bike builds, providing professional-grade charging for personalized e-bike projects.
